The Audioline HD-306 Piezo Tweeter is a high-efficiency professional audio tweeter designed to deliver clear, sharp, and powerful high frequencies for PA systems, speaker cabinets, and sound reinforcement setups. With a wide frequency response from 5kHz to 20kHz and 107dB SPL sensitivity, it ensures crisp treble output even at high volume levels.
This tweeter comes with capacitor support and is engineered for flexible installation, making it suitable for use with heavy, medium, or small woofers. Ideal for DJ speakers, church sound systems, mobile PA, and custom speaker builds.
🔊 Key Features & Benefits
• 700 Watts Power Handling – Delivers strong and clear high-frequency output
• Piezo Tweeter Design – High efficiency with minimal power loss
• Wide Frequency Response (5kHz–20kHz) – Crisp and detailed treble sound
• High Sensitivity (107dB SPL) – Loud output even at low power input
• 4 Ohms Impedance – Compatible with most PA audio systems
• Capacitor-Based Protection – Prevents damage and improves sound clarity
• Flexible Installation Options – Suitable for various woofer sizes
🛠️ Specifications
Specification
Brand: Audioline
Model: HD-306
Type: Piezo Tweeter
Max Power: 700 Watts
Impedance: 4 Ohms
Frequency Response: 5kHz – 20kHz
Sensitivity: 107 dB (1 meter / 1 watt)
Capacitor Voltage: 63V Non-Polarized Electrolytic
Application: PA Speakers, DJ Systems, Speaker Cabinets
