Specification
Model: M-5815CH
Rated Voltage: 220VAC-60Hz
Capacity: 1500VA/900W
INPUT:
Voltage: 220/230/240Vac (Label specified)
Voltage Range: -30%, +25%
Frequency: 50Hz or 60Hz (Auto-sensing) (Label specified)
BATTERY:
Voltage: 24VDC
Recharge Time: 5hours to 90% after complete discharge
Safety Protection: Over charge & over discharge protection
ENVIRONMENT:
Operating Temperature: 0°C-40°C(32°F-104°F)
Humidity: 0-95°%, non-condensing
Acoustic Noise: <40 dB at 1m
OUTPUT:
Voltage Regulation: +/-10% (Label specified)
Frequency: 50Hz or 60Hz +/-1Hz
Waveform: Simulated Sinewave
Transfer Time: <6ms(typical)
AUDIBLE ALARM:
Battery Mode: Two short tones every 8 seconds
Low battery: Four short tones every seconds
Fault: Beeping continuously
PHYSICAL:
Cord Length: 1.5m
Weight: 8.9kg
Dimension: 34.3(L) x 13.5(W) x 20.6(H)cm
-Features-
Line interactive UPS Design
Controlled by a technologically advanced microprocessor guaranteeing
Equipped with 2-steps boost & 1-steps buck AVR to stabilize output voltage
Built-in DC start function enables UPS to be started without AC power supplied
Constant current, constant voltage battery charger (CCCV battery charger)
No-load shut down function (UPS Green mode)
UPS will charge itself even though power switch is off (Off mode charging)
Over/under voltage protection (UPS will go to battery mode)
Cold start function (DC power on)
Battery easy replacement design
